Axxess AX-LOC2.4-PRO
Specifications:
This 4-channel Active LOC with Bass Boost from Axxess has universal applications and enables installers to add aftermarket amplifiers to OEM source units for enhanced sound quality. This advanced technology features incredible input power capabilities, a load selector, clip indicator, enhanced output controls, and noise isolation countermeasures. Add the Axxess AX-RM1 external Bass knob for additional subwoofer adjustments. This supplemental product will directly plug into the Axxess PRO series LOC’s and line driver.
Features
4-channel: 2 in, 4 out
Max input level: 40V / 400W @20K Ohm
Operating voltage: 9V-16V
0dB + 12dB (rear channels)
Optional PR-RM-1
Trigger selection: REM / DC / AUDIO
Turn on trigger (DC): 3V-7V
Output max @13.8V: 9.5V RMS
Input impedance selection: 20 / 60 / 20k Ohm
Ground selection: GND / ISO / 200 Ohm
Gain adjustment: – 28dB to +1dB
Input sensitivity: 0.5V-20V
Signal to noise: >110dB @6.4V output
THD+N (Total Harmonic Distortion): <0.01%
Frequency response: 20Hz – 20kHz
Low pass filter: <250Hz (rear channels)
Bass boost: 0dB + 12dB (rear channels)
Remote control: optional AX-RM1
|
