SounDigital 1600.1EVOX2-2OHM



SOUNDIGITAL, EVOX2 1600.1 MONOBLOCK AMPLIFIER 1600W RMS @ 2 OHM WITH BASS BOOST & ADJUSTABLE FILTERS
EVOX2 1600.1 monoblock amp with 1600W RMS @ 2 Ohm, bass boost, adjustable filters, and 89% efficiency.
PART#: 1600.1EVOX2-2OHM

Login to View Pricing

Specifications:
  • Power @ 1Ω: N/A
  • Power @ 2Ω: 1 X 1600W RMS
  • Power @ 4Ω: 1 X 1056W RMS
  • Frequency Response (-3dB): 5Hz – 25kHz
  • Subsonic Filter (12dB/octave): 5Hz ~ 40Hz
  • Low Pass Filter (12dB/octave): 50Hz ~ 500Hz
  • Operating Voltage: 8V – 16V
  • SNR: 94dB
  • Input Sensitivity (RCA): 0.2V ~ 2.5V
  • Input Sensitivity (High Level Input): 1.4V ~ 14V
  • Current Draw (Music): 1Ω: 65A & 2Ω: 62A
  • Current Draw (Max): 1Ω: 125A & 2Ω: 115A
  • Total Efficiency: 89%
  • Damping Factor: >3000
  • Power Cable: 16mm² (5 AWG)
  • Speaker Cable:
  • 2Ω: 2 x 4mm² (14 AWG)
  • 4Ω: 2 x 2.5mm² (13 AWG)
  • Recommended Fuse (Music): 80A
  • Recommended Battery (minimum): 80Ah
  • Width: 5.3 in / 13,6 cm
  • Length: 7 in / 18 cm
  • Height: 2.1 in / 5,5 cm
